2015 CHEVROLET CORVETTE for sale in FEDERAL WAY

ADVERTISED
PRICE

BUYING TOOLS

BASICS

VIN:	1G1YT2D61F5600535
Stock #:	WSM2451
Odometer:	34618
Paint Color:	RED
Type:	N / A

PERFORMANCE

Transmission:	MANUAL, 7-SPD
Engine:	6.2L SUPERCHARGED LT4 V8 ENGINE
Drive:	REAR WHEEL DRIVE
Fuel:	GAS

DESCRIPTION

Nationwide Shipping Available
Financing Available

2015 Chevrolet Corvette Z06 3LZ

VIN: 1G1YT2D61F5600535
Stock #: WSM2451
Exterior: Torch Red
Interior: Jet Black
Transmission: 7-Speed Manual with Active Rev Matching

Factory Features

6.2L Supercharged LT4 V8 Engine
650 Horsepower
650 lb-ft Torque
7-Speed Manual Transmission with Active Rev Matching
Rear-Wheel Drive
Dry-Sump Oil System
Electronic Limited-Slip Differential
Performance Traction Management
Magnetic Ride Control
Z07 Performance Package
Brembo Carbon Ceramic Brakes
Competition Sport Bucket Seats
3LZ Preferred Equipment Group
Carbon Flash Painted Ground Effects Package
Carbon Flash Badge Package
Red Brake Calipers
Performance Exhaust System
Head-Up Display
Performance Data & Video Recorder
Heated & Ventilated Front Seats
Power Bolster & Lumbar Adjustment
8-Way Power Front Seats
Custom Leather-Wrapped Interior Package
Sueded Microfiber-Wrapped Upper Interior Trim Package
Flat-Bottom Leather-Wrapped Steering Wheel
Bose Advanced 10-Speaker Audio System
Dual-Zone Automatic Climate Control
Rear Vision Camera
Universal Home Remote
Cruise Control
HID Xenon Headlights
LED Daytime Running Lights
Heated Power Exterior Mirror

Factory Added Options

3LZ Preferred Equipment Group – $8,650
Competition Sport Bucket Seats – $2,495
Z07 Performance Package – $7,995
Carbon Flash Painted Ground Effects Package – $2,995
LPO Cargo Shade – $170
Original Shipping Charge – $995
Total Original MSRP: $110,445

Upgrades

Supercharger / Induction

Magnuson 2650 Supercharger
103mm Upgraded Inlet Snout
THPSI 2650 Billet Lid
Soler Performance 107mm Throttle Body
Roto-Fab 5" Big Gulp Intake
DSX Idler Bracket System
DSX 9.25" Lower Pulley
DSX 80mm Upper Pulley
Gates Green Belt

Engine / Cylinder Heads / Valvetrain

Frankenstein Stage 2 Ported LT4 Heads
Frankenstein Titanium Valves & .700 Springs
Cam Motion Stage 4 Cam 232/250
CHE Trunnion Upgrade
ARP Head Studs
Katech Gen 5 LT4 AFM Delete Valley Cover
VVT Phaser Lock Block
DSX Aluminum Valve Covers
ATI Harmonic Damper
Iridium Spark Plugs Gapped to .028
ACCEL Extreme 9000 Spark Plug Wire Set

Fuel System / Methanol

DSX Low-Side Fuel System
AEM 400 Fuel Pump
DSX Atlas Port Injection System
DSX Atlas Port Injection Plates
Injector Dynamics 1050cc Injectors
DSX Flex Fuel System
Alky Dual Injection Methanol System with Dual M15 Nozzles
DSX Dual Widebands

Cooling

DeWitts Oil Cooler
DeWitts C7 Corvette 19" Brushless Electric Fan
DeWitts 70mm HP Series Radiator
DeWitts C7 Corvette Heat Exchanger
Cordes Performance Expansion Tank
160-Degree Thermostat
LaSilva Aluminum Thermostat Cover
Crankcase Ventilation
Dual Mighty Mouse C7 Z06 Wild Catch Can System

Exhaust

American Racing 2" Full Headers & X-Pipe
Corsa 2.75" Xtreme Axle-Back Exhaust with Quad Black Tips

Drivetrain

McLeod 1200X Dual Plate Clutch Kit
MGW Short Throw Shifter
Black Shift Knob with White H-Pattern

Wheels & Fitment

19" Signature SV309 Forged 3-Piece Wheels – Gloss Black

Exterior / Carbon Fiber

R Style Carbon Fiber Front Splitter
Carbon Fiber Fender Vents
OEM Style Carbon Fiber Side Skirts
EOS Carbon Fiber Rear Quarter Panel Intake Vents
Carbon Fiber Spoiler with Wicker Bill
Top Flight Automotive Carbon Fiber Roof
APR Style V2 Carbon Fiber Rear Diffuser
Carbon Fiber Quarter Extensions
Dual Anderson Composites Hood Vents
ACS Composite Hood Heat Extractor Kit

Interior / Electronics

Custom Carbon Fiber & Leather Steering Wheel
P3 Vent Gauge
Carbon Fiber Wrapped Interior Trim

Tuning / Performance

Dyno Tune by THETA Motorsports
Performance Output
1,045 WHP
808 lb-ft Torque

Finished in Torch Red over a Jet Black 3LZ interior, this 2015 Chevrolet Corvette Z06 represents an extensively developed four-digit-horsepower C7 build combining a Magnuson 2650 supercharger system, heavily upgraded LT4 top end, comprehensive fueling and cooling systems, reinforced drivetrain, premium forged wheels, and extensive carbon fiber bodywork. From the factory, the Z06 features Chevrolet's supercharged 6.2-liter LT4 V8 paired in this example with the highly desirable 7-speed manual transmission with Active Rev Matching.

This example was exceptionally well equipped from the factory with the 3LZ Preferred Equipment Group, Z07 Performance Package, Competition Sport Bucket Seats, and Carbon Flash Painted Ground Effects Package. The 3LZ specification adds an extensively leather-trimmed cabin with a Sueded Microfiber-Wrapped Upper Interior Trim Package, while the Z07 package further enhances the Z06's track-focused chassis. Its original factory specification resulted in an MSRP of $110,445.

At the center of the build is a Magnuson 2650 supercharger upgraded with a THPSI billet 2650 lid and 103mm inlet snout. A Soler Performance 107mm throttle body and Roto-Fab 5-inch Big Gulp intake provide additional airflow, while a DSX 9.25-inch lower pulley, 80mm upper pulley, idler bracket system, and Gates Green belt complete the upgraded supercharger drive configuration.

The LT4 top end has received substantial development with Frankenstein Stage 2 ported cylinder heads, Frankenstein titanium valves and .700 springs, and a Cam Motion Stage 4 232/250 camshaft. Supporting valvetrain and engine hardware includes a CHE trunnion upgrade, ARP head studs, Katech Gen 5 LT4 AFM Delete Valley Cover, VVT phaser lock block, DSX aluminum valve covers, and ATI harmonic damper. Iridium spark plugs gapped to .028 and ACCEL Extreme 9000 plug wires provide additional ignition support.

Fuel delivery is comprehensively upgraded with a DSX low-side fuel system and AEM 400 pump feeding a DSX Atlas port injection system with dedicated plates and Injector Dynamics 1050cc injectors. A DSX flex-fuel system provides additional fueling versatility, while an Alky dual-injection methanol system with dual M15 nozzles and DSX dual widebands provide further support and monitoring for the high-output combination.

Cooling has received equally extensive attention. A DeWitts 70mm HP Series radiator, C7 Corvette 19-inch brushless electric fan, heat exchanger, and dedicated oil cooler provide substantially upgraded thermal management. A Cordes Performance expansion tank, 160-degree thermostat, and LaSilva aluminum thermostat cover complete the cooling package, while a dual Mighty Mouse C7 Z06 Wild catch can system provides upgraded crankcase ventilation.

Exhaust flow is handled through American Racing 2-inch full headers and X-pipe feeding a Corsa 2.75-inch Xtreme axle-back exhaust with quad Black tips. The combination provides a substantially more aggressive exhaust character while supporting the airflow requirements of the modified LT4.

The drivetrain has been reinforced with a McLeod 1200X dual-plate clutch kit to support the substantially increased output. An MGW short throw shifter and Black shift knob with White H-pattern provide a shorter and more direct interface with the 7-speed manual transmission.

The Corvette rides on premium 19-inch Signature SV309 forged three-piece wheels finished in Gloss Black. The forged wheel setup complements the Torch Red exterior and extensive exposed-carbon treatment while providing an appropriately high-end fitment for the level of the overall build.

Exterior modifications are extensive, highlighted by a Top Flight Automotive carbon fiber roof, R Style carbon fiber front splitter, carbon fiber fender vents, OEM Style carbon fiber side skirts, EOS carbon fiber rear quarter intake vents, carbon fiber spoiler with wicker bill, APR Style V2 carbon fiber rear diffuser, and carbon fiber quarter extensions. Dual Anderson Composites hood vents and an ACS Composite hood heat extractor kit further transform the hood while providing additional heat extraction for the high-output supercharged combination.

Inside, a custom carbon fiber and leather steering wheel creates a more performance-focused driver interface, while a P3 vent gauge provides additional vehicle monitoring. Carbon fiber wrapped interior trim carries the exterior carbon theme into the 3LZ cabin.

Professionally dyno tuned by THETA Motorsports, the completed combination produces an impressive 1,045 wheel horsepower and 808 lb-ft of torque.

With over $123,000 represented by parts and professional installation, this Z06 combines a Magnuson 2650 supercharger, extensively upgraded LT4 top end, comprehensive port-injection and flex-fuel system, methanol injection, extensive cooling, a McLeod dual-plate clutch, premium Signature three-piece wheels, and extensive carbon fiber bodywork into a serious four-digit-horsepower C7 build.

We offer nationwide shipping and easy financing for all credit types.
Call or text 425-200-5976 for details or to schedule your test drive.
Visit www.WSMWA.com

West State Motorsport
1710 S 344th St, Federal Way, WA 98003
